제품 정보
1/3 inch IT CCD
600 TV Lines (BW 650TVL)
Built-in Fixed Lens (f=6mm)
Intelligent IR Technology
IR LED 36EA
Color 0.00005Lux, IR LED On 0.00Lux
Auto White Balance
Weather Proof Housing
65mm in Diameter
12VDC
Model
KIR-41F
Signal System
NTSC
Scanning System
2:1 Interlace
Scanning Frequency (H)
15.734 KHz
Scanning Frequency (V)
59.94 Hz
Image Sensor
1/3 Inch IT CCD
Total Pixels
811(H) x 508(V) 410K
Effective Pixels
768(H) x 494(V) 380K
Horizontal Resolution
600 TV Lines
Video Output
1.0V p-p (75Ω, Composite)
S/N Ratio
More than 50dB(AGC Off)
Lens
Built-in Fixed Lens (f=6mm)
Min.Illumination
0.00005 Lux (Color), 0.00 Lux (IR LED On)
IR LED and Sensor
Intelligent IR Technology, IR LED 36EA (850nm, 30˚)
IR LED Visible Range
Max. 30m
White Balance
Auto
Shutter Speed
1/60~1/120,000 sec.
Supplied Voltage
DC 12V
Power Consumption
Max. 6W/0.5A
Dimensions
78.0 x 150.0mm
Weight
Approx. 800g
|
 |
|
|
|
|
|
|
|
|
|
|
